Description
The Automatic Flat Aluminum Stainless Steel Letter Bending Machine AEL-M120 is a high-precision CNC solution designed for fabricating aluminum and stainless steel channel letters, logos, and custom signage. Engineered for professional sign manufacturers, this machine delivers fast, accurate bending with minimal setup, making it an excellent choice for both custom projects and high-volume production.
Built to process a variety of flat metal materials, the Automatic Flat Aluminum Stainless Steel Letter Bending Machine AEL-M120 is capable of bending flat aluminum, stainless steel, and galvanized steel with exceptional precision. Its servo motor-driven feeding system and ball screw transmission provide smooth, accurate material handling while preventing deformation during processing. The dual-axis telescopic bending structure allows for tight-radius bends and complex shapes with minimal manual finishing.
The Automatic Flat Aluminum Stainless Steel Letter Bending Machine AEL-M120 features a closed-loop feeding system capable of material positioning accuracy up to 0.01mm, ensuring every finished letter matches the original design. With support for common vector file formats including AI, PLT, DXF, and NC, the machine integrates seamlessly into modern sign manufacturing workflows.
Designed for reliability and efficiency, the Automatic Flat Aluminum Stainless Steel Letter Bending Machine AEL-M120 incorporates premium alloy tooling that eliminates the need for grinding while extending tool life. Combined with intelligent software, modular electronics, and high-performance servo control, it delivers consistent, professional-quality results for a wide range of commercial signage applications.
Key Features:
- Designed for aluminum, stainless steel and galvanized steel letters
- High-precision servo motor control system
- Ball screw transmission for accurate material feeding
- Closed-loop feeding system with 0.1mm positioning accuracy
- Dual-axis telescopic bending structure for complex shapes
- Mechanical arm alternating feeding system
- Long-life alloy bending knives requiring no grinding
- Supports AI, PLT, DXF, NC, and other vector file formats
- Modular electrical control system for increased stability
- High-speed processing with minimal material deformation
Material Capacity:
Material Width: 20-120mm
Material Thickness:
- Stainless Steel: 0.3-2.0mm
- Galvanized Steel: 0.4-1.2mm
- Flat Aluminum: 0.6-1.5mm
Compatible Materials:
- Flat Aluminum
- Stainless Steel
- Galvanized Steel
Applications
The Automatic Flat Aluminum Stainless Steel Letter Bending Machine AEL-M120 is ideal for producing:
- Channel letters
- Stainless steel letters
- Aluminum letters
- Commercial signage
- Storefront signs
- Corporate logos
- Illuminated signs
- Architectural signage
- Custom metal lettering
- Advertising displays
Advanced Components
- Closed-loop feed feedback system
- Ball screw transmission with servo motor control
- Dual-axis telescopic bending system
- Mechanical arm alternating feeding structure
- Korean alloy plane cutter
- Integrated IO PCB control board
- Modular electrical control system
- Intelligent CNC software with multi-point slotting capability
Optional Equipment
- Industrial PC with pre-installed software and tested parameters
- Planar cutter for slotting stainless steel and flat aluminum
- Air supply system, (0.6-0.8 MPa)
The Automatic Flat Aluminum Stainless Steel Letter Bending Machine AEL-M120is an ideal solution for sign manufacturers seeking precision, speed, and versatility when producing aluminum and stainless steel channel letters. Combining advanced CNC technology, servo-driven accuracy, and durable construction, the Automatic Flat Aluminum Stainless Steel Letter Bending Machine AEL-M120 delivers consistent professional-quality results for a wide variety of commercial signage applications.
